UNI-T UT302 Infrared Thermometer

UNI-T UT302 Infrared Thermometer

UT302D series is a professional non-contact infrared thermometer that can determine the temperature by testing the infrared energy on the surface. It is used for fast and safe fault detections and maintenance of electric instrument and equipment, engines, motors, and HVAC refrigeration system.

Model Number Range
UT302D -32°C ~1050°C

ADD TO CART to buy or to Request for Quotation (RFQ)

GET QUOTATION


Cart

DESCRIPTION

UT302D series is a professional non-contact infrared thermometer that can determine the temperature by testing the infrared energy on the surface. It is used for fast and safe fault detections and maintenance of electric instrument and equipment, engines, motors, and HVAC refrigeration system.
Features
°C/°F Selection √
Laser Switch √
Display Hold (s) 8 Seconds
Data Hold √
Auto Power Off √
Low Battery Indication √
MAX Mode √
MIN Mode √
DIFF Mode √
AVG Mode √
LCD Backlight √
Electricity Cut-off Memory √
Tripod Mount √
General Characteristic
Power 9V Battery (6F22)
LCD Size 32mm X 29mm
Product Color Red and Grey
Product Net Weight 322g
Product Size 169mm X 138mm X 53mm
Standard Accessories Battery, Carrying Bag, USB Cable (External Power)
Standard Individual Packing Blister, English Manual
Standard Quantity Per Carton 20pcs
Standard Carton Measurement 628mm X 345mm X 468mm (0.101 CBM Per Standard Carton)
Standard Carton Gross Weight 13kg

SPECIFICATIONS

Specifications Range
Model UT302D
Temperature Range -32°C~1050°C
-26°F~1922°F
Accuracy ±1.8°C or ±1.8%
Repeatability ±0.5°C or ±0.5%
Resolution 0.1°C/0.1°F
Distance to Spot Size 20:1
Response Time 250mS (95% of reading)
Emissivity 0.10~1.0 Adjustable
Laser Type Class 2 (Ⅱ)
Laser Power <1mW
Laser Wavelength 630nm~670nm
Spectral Response 8μm~14μm
